Rheem water heaters with special features to ensure the heater is safer, more reliable and works longer...

•
  Exclusive Rheemglas enamel tank protection against corrosion by coating the inner tank with an exclusive Rheemglas and fused with solid steel at 870ºC. The result is a smooth, tough glass-like lining that effectively resists the corrosive attack of hot water chemicals and ensures a longer life span on Rheem heaters. Tank is designed and tested to withstand 2000kpa hydrostatic test pressure for pressure of 1000kpa.
• UL approved combined temperature and pressure relief (TPR) safety valve provides protection against excessive water pressure (Pre-set at 0.98Mpa). The TRP allows tank to be manually drained off to facilitate servicing.
• Adjustable thermostat with over temperature protection is a safety device that automatically and safely cuts off the power in the event the preset temperature is exceeded, thus prevents scalding by hot water. Thermostat conserves electricity by cutting-off power supply to the heater once it has reached the preset temperature.
• Incoloy sheathed immersion heating element promotes longer, more efficient performance. Efficient heat transferring design reduces sediments built-up in tank.
• Anode rod protects the inner tank from corrosion by equalizing agressive water reaction. Thus extending the lifespan of Rheem heaters.
• CFC free polyurethane insulation between inner tank and epoxy coated steel jacket provides maximum heat retention and minimize operating after year of service.
• Compliance to international requirement IEC 60335-2-21 and U.L 174. Tested and approved by PSB Corporation.

Model

Tank Capacity


Stainless Steel Element

Operating
Weigh
t(Kg)

Heater Dimension

Shipping
Weight
(Kg)

Shipping Dimension

Current Draw (amps)

Over Current Protection (amps)

Approx.* Heat up
Time to 60ºC

USG

Litres

Vltage

(Kw)

Dia
(mm)

Ht (mm)


L (mm)

B (mm)

Ht (mm)

85VP6S

6

23

240V

1.5 / 3.0

40

400

390

17

460

420

420

6.25/12.5

15

19 mins

65SVP10S

10

38

240V

1.5 / 3.0

57

400

445

19

460

420

470

6.25/12.5

15

31 mins

65SVP15S

15

57

240V

3.0

83

450

510

26

510

470

540

6.25/12.5

15

46 mins

85VP20S

20

76

240V

3.0

108

500

640

32

560

520

670

12.5

15

61 mins

85VP30S

30

113

240V

3.0

156

553

770

43

620

570

810

12.5

15

92 mins
